3
Specication
Electrical
Physical
Environment
Accreditation
Disposal
Input and Resolution
EU Directive 73/23/EEC (Low Voltage Directive)
BS EN 55022:1998 Class B
BS EN 55024:1998
Input to Power Supply Unit (Supplied)
100-240V (47-63Hz)
External switch-mode - Output voltage 15VDC
Input Voltage to NMS100 12-27VDC ±10%
Conforms to Low Voltage Directive
Height 188mm (7.4”) Depth 48mm (1.89”)
Width 306mm (12.072”) Weight 0.5kg (1.1lb)
Climatic Range Storage Temperature -20°C to 70°C
Working Temperature -10°C to 50°C
Working Humidity 95% R.H. at 31°C
IP-Ingress Protection IP40 Stand Alone, IP54 Panel Mount
CE UKCA
At the end of its life, please dispose of the NMS800 Digital in a safe manner applicable to electrical
goods
Do not burn
The casework is suitable for recycling. Please consult local regulations on disposal of electrical equipment
Either the Newall ‘serial’ or ‘digital’ encoders support a TTL output can be used with the NMS800 DRO
depending on which model.
Resolutions
Dependant on Encoder (Linear) Dependant on Encoder (Rotary)
0.1µm (0.00001”) Program PPR, 0 - 90,000,000
0.5µm (0.00002”)
1µm (0.00005”)
2µm (0.0001”)
5μm (0.0002”)
10μm (0.0005”)
