7. SYSTEM CONTROLS
The ON-OFF control button is used not only to turn on and off
the device, but to activate the MENU as well. One short press on
this button activates the screen menu that controls brightness and
contrast of the screen. An extended press of this button in the
main mode turns the device off. The arrow buttons control zoom
and image presentation scheme in the main mode and change the
brightness and contrast in the menu mode. The table below
describes the functionality of each control button.
Control Button Functionalities in the Main Operating Mode
Control Button
Diagram and Name
, result of rapid press
(≤0.5 seconds)
, result of extended
press (≥1.0 second)
Button 3*
WH|BH
Toggles between ‘white
hot’ , ‘black hot’ , ‘sepia’
and ‘rainbow’ image
scheme
Triggers sensor calibration
Button 1*
ON/OFF
Menu Turns the device on and off
Button 2*
ZOOM
Switches between zoom
values (1x, 2x, 4x)
Shows/removes frame on
the display
*see page 5 for details
