8. DISPLAY
In the main mode display provides an image of the observed
object. Permanently depicted service information includes the
battery status indicator and zoom number (if different from 1x).
Information about image presentation appears for five seconds
after this parameter is changed. In the menu mode the user can
control brightness and contrast settings. After exiting the menu
mode, the user is returned to the main mode window.
Icon
Display
Zone
Icon Description
Icon Display Conditions
I
1
A1 Recording is active
During recording
I
1
A1 Pause during recording
1 sec
I
1
A1 Single screen capturing
1 sec
I
1
A1
Sequence of screen
capturing
Only during recording
I
С1 Calibration
1 sec
B3
Chosen digital
magnification value
Permanently (х1 is not
displayed)
C3 Battery charge status
When the unit is powered by
the battery set
1
Optional function. Available only if recording feature is supplied
x4
х2
