Movement Limit & Self-stop Positions
Change the Displayed Unit (cm / inch)
Amend the Desktop Height Displayed
Enable this function only when you are really
need in some situation.
1. Keep pressing the key “S” for 3 seconds "HLP". until the display shows "S--" to enter
2. Press up key till the display flash as “HLP”.
3. Press “1”, the display show alternately as “H-P” and current height.
4. Keep pressing up or down key till the required upper limit position is reached.
5. Press “S”, the desktop height will be showed and the self-stop position has been set.
6. Press “2”, the display will show alternately “L-P” and current height, keep pressing down key till
the low limit position is reached, press S the Movement limit & self-stop position has been set.
1. Keep pressing the key “S” until the display show “S--” to enter the setup menu.
2. Press up key until the display will show “Unt”.
3. Press “1”, and the display will show alternately as “Unt” and the desktop current height value
of by “cm”.
4. Press "S" key to save the unit as cm.
5. Press "2", and the display will show alternately as "Unt" and the desktop current height value by
"inch", press key "S" to save the unit as inch.
1. Keep pressing key "S" till the display show "A--"
2. Briefly Press “UP” or “Down” key, until the display show alternately as “End” and current
height. (At this point, the units display mm or inch).
3. Press "1", "2" ,"3" to choose the first, second and the third number, each click will increase one
value.
4. Press "S" , the amending has been set.
Note: By this function would be used to limit the height movement of desk. Once it is set, the new upper or lower
limitation position will be stored.
Note: The function enables you to change the height shows on the display based on the actual measurement.
