2.2.6 DASHBOARD TOOLS
AUDIO (HEADPHONES)
You can connect a headset to the (green) audio output jack on the rear of NC1 IO's motherboard.
1 2
Controls for Headphone audio are found in the lower-left corner of the
dashboard at the bottom of the screen Figure 27).
1. The audio source supplied to the Headphone jack can be selected using
the menu next to the headphone icon (Figure 28).
2. The Volume for the selected source can be adjusted moving the slider
provided at right (double-click this control to reset it to the default 0dB
value).
RECORD
FIGURE 29
The Record button is also located in the lower-right corner of the dashboard (Figure 29). Click it to open a
widget allowing you to begin or stop recording of individual channels (or start/stop all recordings.)
Notes: The destinations for recorded clips, their base file names and other settings are controlled in the
Configuration panel ( Figure 9). Recording NDI sources is not supported. The Share Local Recorder Folders
can be used to expose local folders assigned to capture duties on your network, making it easy to access
captured files externally.
