Before beginning assembly, make sure all parts are present. Compare parts with package contents list and
diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
•Tools Required for Assembly:
Phillips Screwdriver (not included) and Wrench (not included)·
• Note: The left and right sides of the grill are on your left and right as you face the front of the grill.
Hardware Pack Contents
AA BB
CC
DD EE
GG
FF
Preparation
Phillips Screwdriver Wrench
7
81/4-in. x 65-mm Round Head ScrewFF
81/4-in. Flat WasherGG
1Allen KeyEE
181/4-in. Lock WasherDD
181/4-in. x 10-mm Round Head ScrewCC
265/32-in. Lock WasherBB
265/32-in. x 8-mm Round Head ScrewAA
Required for assembly
(pcs)
DescriptionPack
To Next Page
