Assembly Instruction
STEP 4. Attach the Post
● Put the head assembly into the post.
● Please make sure the Gas Hose
End and two wires go through the post.
Do not secure the heat assembly in
this step.
STEP 3. Attach the Emitter Grid
● Put the Emitter Grid on the Emitter
base.
● Secure the Emitter Grid with 4pcs
3/16” x 10mm Truss Head Screws as
shown in the diagram to the left.
6
To Next Page
