Nexigo PJ10 - Projector Diagram and Controls

KEYSTONE
1. AV Input Port
2. 3.5mm Audio Jack
3. HDMI Input Port
4. USB Input Port/Screen Monitor
5. USB Input Port
6. Keystone Adjustment
7. Power Input Jack
8. Focus Adjustment
9. Vol+/Vol-/Left/Right
10. Power Switch
11. Up
12. Down
13. OK
14. Return
15. Lens
PROJECTOR DIAGRAM
2
4
6
10
11
12
13 14
15
9
7
8
1
3
5
US 01US 02
