PROJECTOR DIAGRAM
1. Lens
2. Focus Adjustment Wheel
3. Air Filter
4. Power Switch
5. Home Button
6. Return Button
7. OK Button
8. Left / Right / Up / Down Buttons
9. Power Input Port
12
3
15
FRONT VIEW SIDE VIEW
REAR VIEW BOTTOM VIEW
457
6
8
10. RJ45 Port
11. USB Input Ports
12. HDMI Input Ports
13. 3.5mm Audio Jack
14. AV Input Port
15. IR Receiver
16. Manual Lift Stand
17. Feet / Mounting Slots
17
16
17
9
10 11 12
13 15
14
EN 02
