Next DMX 512 User Manual

This function allows to pair the receiver Wi D Pen to the transmitter Wi
DMX, to avoid interactions with other unit of the same type.
4.6 RECEIVER PAIRING
With MODE key (Fig.17) find the text like in (Fig.18).
Connect Wi D Pen to the
DDMMXX 551122 ttrraannssmmiitttteerr
signal
IINN
(Fig.20/1) without connecting Wi D Pen ac-adapter.
Hold SET key (Fig.19) until a writing appears like in (Fig.20).
After a few seconds a result of the operation is given; if like in (Fig.21) pairing succeeded ;
else the message of (Fig.22) appears.
Fig. 17
MODE
SET
Fig. 19
PAIR RECEIVER
Fig. 18
PAIRing
:
wait...
Fig. 20
Fig. 20/1
PAIRing
:
<ok!>
Fig. 21
PAIRing
:
failed!
Fig. 22

Next DMX 512 Specifications

General

Brand	Next
Model	DMX 512
Category	Transceiver
Language	English
