Next DMX 512 User Manual

This operation mode allows you to receive the DMX 512 signal coming from a Wi
DMX transmitter, provide it to the connected projectors and re-transmit it to other
receiver unit.
6.1 EXTENDER MODE
The connection must be like in (Fig.43).
In this mode switch terminator to
OONN
WWii DDMMXX
receives the Radio signal and shows
the number of channels generated
(Fig.44);
in
absence of Radio or DMX signal the display
appears like in (Fig.45).
dmx
:
512ch, 40hz
Fig. 44
dmx
:
<<no data>>
Fig. 45
15
3
42
15
3
42
DMX to other
projector
Terminator
Fig. 43
