This function allows to pair the Wi DMX set as receiver with a Wi DMX set
as trasmitter, to avoid interactions with other unit of the same type. For
this operation you need a DMX signal cable connected between the two unit.
5.6 PAIRING WITH TRANSMITTER (GET PAIRING)
Remove any cable on the DMX connectors and connect the DMX
signal cable between the two unit.
On the
RREECCEEIIVVEERR WWii DDMMXX
, with MODE key (Fig.29)
find the text like in
(Fig.30).
On the
TTRRAANNSSMMIITTTTEERR WWii DDMMXX
, with MODE key (Fig.29)
find the text like
in
(Fig.31).
On the
RREECCEEIIVVEERR WWii DDMMXX
hold SET key (Fig.32) until a writing appears
like in (Fig.33).
On the
TTRRAANNSSMMIITTTTEERR WWii DDMMXX
hold SET key (Fig.32) until a writing
appears like in (Fig.34).
After a few seconds a result of the operation is given; if like in (Fig.35) on both unit, pai-
ring succeeded; else the message of (Fig.36) appears.
Fig. 29
MODE
PAIR RECEIVER
PAIRing
:
wait...
Fig. 34
get pairing
PAIRing
:
reading
Fig. 33
PAIRing
:
<ok!>
PAIRing
:
failed!
Fig. 36
RECEIVER Wi DMX TRANSMITTER Wi DMX
Fig. 32
SET
Fig. 30 Fig. 31
Fig. 35
