With MODE key (Fig.51) find the text like in (Fig.52).
To change the receiver band hold SET key (Fig.53) until the value
changes (Fig.54).
Slow blinking: Receiver
OOKK
, no
DDMMXX 551122
signal.
Fast blinking: Channel research.
Switched on : Receiver
OOKK
,
DDMMXX 551122
signal
OOKK
.
NN..BB
.: If a Radio channel between
00RR aanndd 99RR
is used, the led is
RReedd
.
If a Radio channel between
00GG aanndd 99GG
is used, the led is
GGrreeeenn
.
This function allows to visualize the state of the receiver and to change the
receiver band.
6.4 SETTING OF RX2
6.5 LED 2 FUNCTION
Fig. 51
rX2
:
128ch C
:
0g
Fig. 52
rX2
:
128ch C
:
0r
Fig. 54
rX2
:
no data C
:
0g
Fig. 52
rX2
:
searching...
Fig. 52
MODE
Reception OK
Reception OK
no DMX signal
Radio channel research
Radio band changed
SET
Fig. 53
This function allows to pair the receiver Wi D Pen to the TX1 of the Extender
Wi DMX.
Follow the instructions at
(v.par.4.6)
6.6 RECEIVER PAIRING
This function allows to pair the RX2 of the Extender Wi DMX with a Wi DMX
set as trasmitter.
Follow the instructions at
(v.par.5.6)
6.7 PAIRING WITH TRANSMITTER (GET PAIRING)
This function allows to pair the RX2 of the Extender Wi DMX with a Wi DMX
set as trasmitter using Wi D PEN.
Follow the instructions at
(v.par.5.7)
6.8 PAIRING WITH TRANSMITTER (GET PAIRING) USING WI D PEN
