NextBase 320XR User Manual

13
Dash Cam Installation (cont.)
6 Remove the adhesive cover layer
Peel back the red cover layer to expose the adhesive surface, ready to mount on your windscreen.
8 Attach the Dash Cam to the windscreen
When you are satisfied with the placement and orientation of the Dash Cam, firmly place the mount
on the windscreen.
6
8
7 Straighten the Dash Cam
Ensure that the Dash Cam is horizontal and faces straight out of the windscreen.
Ensure that objects on the Dash Cam display appear level, and adjust as required.
7

NextBase 320XR Specifications

General

GPS	Yes
G-Sensor	Yes
Parking Mode	Yes
Frame Rate	30fps
Image Stabilization	No
Emergency Record	Yes
Loop Recording	Yes
Night Vision	Yes
Resolution	1080p
Field of View	140 degrees
Storage	MicroSD card up to 128GB
Battery	Built-in rechargeable battery
