Nexxt Viking 150 - 1.3 Panel layout

Nexxt Solutions – Wireless-N 3G router
8
3G USB modem port: This port is used to plug a 3G modem/card.
Reset button: Use it to reset the router to its factory default values.
Micro USB port: This port is used to connect the supplied power adapter.
LAN/WAN port: This RJ45 Ethernet port can be LAN or WAN port depending on the
operation mode selected.
•
•
•
•
1.3 Panel layout
1.3.1 Polaris 150
1.3.2 Viking 150
Figure 1-1
Figure 1-2
