Dimensions
Figure 2 shows the USB-6008/6009 OEM device dimensions.
Figure 2. USB-6008/6009 OEM Device Dimensions in Inches (Millimeters)
0.000 (0.00)
1.300 (33.02) 1.775 (45.09)
–0.150 (–3.81)
–
0.106 (–2.69)
–0.150 (–3.81)
–0.575 (–14.61)
–0.725 (–18.42)
0.119 (3.02)
0.000 (0.00)
0.344 (8.74)
0.516 (13.11)
0.433 (11.00)
0.063 (1.60)
0.000 (0.00)
2.305 (58.55)
2.725 (69.22)
0.650 (16.51)
–0.160 (–4.06)
0.413 (10.49) 0.887 (22.53) 1.025 (26.04)
0.275 (6.99)
0.459 (11.66)
1.645 (41.78)
–0.345 (–8.76)
–0.475 (–12.07)
3.300 (83.82)
2.250 (57.15)
1.990 (50.55)
PIN 33
PIN 34
PIN 1
PIN 2
3x φ 0.125 (3.18)
