4.5 Position OPEN Target Plates (8) so they are in the full upward position for “left-hand” (counter-clockwise) opening valves.
Secure OPEN Target Plates (8) by tightening Screws (37a). See Fig. 6.
4.6 Determine the number of turns required to fully open the valve. See Table 1 for NIBCO valves. You should always confirm
actual turns required to open the valve by counting them.
4.7 Using Table 6, choose the closest “Number of Turns to Open Valve” and the corresponding “Distance Between Targets”
dimension “X”.
4.8 Measure and position both SHUT Target Plates (9) at dimension “X” from OPEN Target Plates (8). See Fig. 6.
4.9 Secure both SHUT Target Plates (9) by tightening Screws (37a) with an Allen wrench.
NUMBER
OF TURNS
TO OPEN
VALVE
DISTANCE
BETWEEN TARGETS
X
INCH MM
10 0.000 0.0
11 0.050 1.3
12 0.150 3.8
13 0.250 6.4
14 0.350 8.9
15 0.450 11.4
16 0.550 14.0
17 0.650 16.5
18 0.750 19.1
19 0.850 21.6
20 0.950 24.1
21 1.050 26.7
22 1.150 29.2
23 1.250 31.8
NUMBER
OF TURNS
TO OPEN
VALVE
DISTANCE
BETWEEN TARGETS
X
INCH MM
24 1.350 34.3
25 1.450 36.8
26 1.550 39.4
27 1.650 41.9
28 1.750 44.5
29 1.850 47.0
30 1.950 49.5
31 2.050 52.1
32 2.150 54.6
33 2.250 57.2
34 2.350 59.7
35 2.450 62.2
36 2.550 64.8
37 2.650 67.3
NUMBER
OF TURNS
TO OPEN
VALVE
DISTANCE
BETWEEN TARGETS
X
INCH MM
38 2.750 69.9
39 2.850 72.4
40 2.950 74.9
41 3.050 77.5
42 3.150 80.0
43 3.250 82.6
44 3.350 85.1
45 3.450 87.6
46 3.550 90.2
47 3.650 92.7
48 3.750 95.3
49 3.850 97.8
50 3.950 100.3
51 4.050 102.9
ADJUSTMENT OF TARGET PLATES
Table 4
