PROGRAM SETTINGS
Program setting of AXC 30 can be performed via the
start guide or directly in the menu system.
START GUIDE
The start guide appears at first start-up after the heat
pump installation, but can also be found in menu 7.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 7.2.1 - Add/remove accessories
Here, you state which accessories are installed for the
compatible product.
To identify connected accessories automatically, select
"Search for accessories". It is also possible to select ac-
cessories manually from the list.
Menu 2.5 - Hot water circulation
Operating time
Setting range: 1 – 60 min
Downtime
Setting range: 0 – 60 min
Period
Active days
Setting range: Monday – Sunday
Start time
Setting range: 00:00 – 23:59
Stop time
Setting range: 00:00 – 23:59
Set hot water circulation for up to five periods per day
here. During the set periods, the hot water circulation
pump will run according to the settings above.
"Operating time" decide how long the hot water circula-
tion pump must run per operating instance.
"Downtime" decide how long the hot water circulation
pump must be stationary between operating instances.
"Period" Here, you set the period of time during which
the hot water circulation pump will run, by selecting
Active days, Start time and Stop time.
NOTE
Hot water circulation is activated in menu 7.4
"Selectable in/outputs" or 7.2.8 "Hot water
comfort".
Menu 7.2.8 - Hot water comfort (AXC)
Activating immersion heater.
Setting range: on/off
Activ. imm heater in heating oper
Setting range: on/off
Activating mixing valve
Setting range: on/off
Outgoing hot water
Setting range: 40 - 65 °C
Shunt amplification
Setting range: 0.1 – 10.0
Shunt waiting time
Setting range: 10 – 300 s
Make settings for the hot water comfort here.
Activating immersion heater.: The immersion heater is
activated here, if installed in the water heater.
Activ. imm heater in heating oper: Activate here
whether the immersion heater in the tank (requires the
above alternative to be activated) is to be permitted to
charge hot water, if the compressors in the heat pump
are prioritising heating.
Activating mixing valve: Activated if mixer valve is in-
stalled and it is to be controlled from AXC 30. When the
option is active, you can set the outgoing hot water
temperature, shunt amplification and shunt waiting time
for the mixer valve.
Outgoing hot water: Here, you can set the temperature
at which the mixer valve is to restrict hot water from
the water heater.
Menu 7.5.3 - Forced control
Here you can force control the various components in
the installation. The most important safety functions
remain active however.
NOTE
Forced control is only intended to be used for
troubleshooting purposes. Using the function
in any other way may cause damage to the
components in your climate system.
Caution
Also see the Installer Manual for the main
product.
25AXC 30 S-series | GB
S
