PROGRAM SETTINGS
Program setting of AXC 30 can be performed via the
start guide or directly in the menu system.
START GUIDE
The start guide appears at first start-up after the heat
pump installation, but can also be found in menu 5.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 5.2.4 - accessories
Activating/deactivating of accessories.
Select: "hot water comfort".
Menu 2.9.2 - hot water recirc.
Here you can make the following settings for hot water
circulation for up to three periods per day:
• How long the hot water circulation pump must run
per operating instance
• How long the hot water circulation pump must be
stationary between operating instances.
Menu 5.3.8 - hot water comfort
Here you can perform the following settings:
• activating imm heater: The immersion heater is activ-
ated here, if installed in the water heater.
• activ. imm heat in heat mode: Activate here whether
the immersion heater in the tank (requires the above
alternative to be activated) is to be permitted to charge
hot water, if the compressors in the heat pump are
prioritising heating.
• activating the mixing valve: Activate if mixing valve is
installed and will to be controlled from the heat pump.
When the option is active, you can set the outgoing
hot water temperature, shunt amplification and shunt
waiting time for the mixer valve.
Menu 5.6 - forced control
Forced control of the different components in the heat
pump as well as in the different accessories that may
be connected.
QZ1-AA5-K1: Activating the relay for extra hot water.
QZ1-AA5-K2: Signal (close) to the mixing valve (FQ3).
QZ1-AA5-K3: Signal (open) to the mixing valve (FQ3).
QZ1-AA5-K4: Activating the circulation pump (GP11).
Caution
Also see the Installer Manual for the main
product.
AXC 30 F-series | GB66
