Outline diagrams
NOTE
These are outline diagrams.
Actual installations must be planned according
to applicable standards.
Explanation
External additional heatEB1
Expansion vessel, closedCM5
External electrical additional heatEB1
Safety valve, heating medium sideFL10
Shut-off valve, heating medium sideQM42
-
QM43
Trim valveRN11
Indoor moduleEB15
Indoor moduleEB15
Heat pump systemEB100
Temperature sensor, outdoorBT1
Temperature sensor, hot waterBT6
Temperature sensor, external flow lineBT25
Temperature sensor, external return lineBT71
Heat pumpEB100
Cooling module AEP14
Cooling module BEP15
Safety valve, collector sideFL10 -
FL11
Safety valve, heating medium sideFL12 -
FL13
Particle filterHQ1
HQ12 -
HQ15
Shut-off valve, brine sideQM50
-
QM53
Shut-off valve, heating medium sideQM54
-
QM57
Reversing valve, heating/hot waterQN10
Non-return valveRM10 -
RM13
Heat pump system (slave)EB101
Heat pumpEB101
Climate system 2 (ECS 40/ECS 41EP21
Unit boxAA25
Flow temperature sensor, extra climate systemBT2
Return line sensor, extra climate systemBT3
Circulation pump, extra climate systemGP20
Shunt valveQN25
Climate system 3 (ECS 40/ECS 41EP22
Climate system 4 (ECS 40/ECS 41EP23
Miscel-
laneous
SMO 40AA25
Manometer, brine sideBP6
Expansion vessel, heating medium sideCM1
Level vesselCM2
Expansion vessel, brine sideCM3
Accumulator tank with solar coilCP10,
CP11
Buffer vesselCP20
Ground-source heating/Ground collectorEP12
Safety valve, heating mediumFL2
Safety valve, brineFL3
Circulation pump, heating medium externalGP10,
GP18
Filler valve, brine
QM12
Venting valve, brine sideQM21
Shut-off valve, heating medium flowQM31
Shut off valve, heating medium returnQM32
Shut off valve, brine returnQM33
Shut off valve, brine flowQM34
Shut-off valveQM42
Non-return valveRM2,
RM21
Trim valvesRN60 -
RN63
Filling set, brineXL15
Connection, filling brineXL27 -
XL28
Designations in component locations according to
standard IEC 81346-1 and 81346-2.
21
GB
