Switch 3 ON: Complete remote reversal
If the safety device triggers when the gate or door is closing, movement will be reversed
completely.
Switch 4 ON: Limit switch excluded
If this function is not going to be used, activate this function instead of linking out the FCA
and FCC contacts.
INFORMATION ON MEASURES TO SAFEGUARD THE ENVIRONMENT
This product is made with different materials that can be recycled.
Inquire about the recycling or disposal systems for the product, in accordance with local
laws.
TECHNICAL DATA
- POWER SUPPLY : 230 Vac +/- 10% 50-60 Hz
- WORKING TEMPERATURE : -20 °C +60 °C
- MAX. MOTOR POWER : 1/2 Hp SINGLE-PHASE
- MAX. OUTPUT CURRENT 24Vac : 100mA
- WORK TIME : Adjustable from 2 to 120 secs.
- COURTESY LIGHT TIME : Fixed at about 45 secs.
- CONTAINER SIZE : 147 x 118 x 52 mm
12
