Device Test
Please verify the device is on the network after installation:
1. Network: Press and hold the Call button to obtain IP address. The network is working
properly if the device announces an IP address. IfnoIPaddressisobtained, the unitwill
announce“IP0.0.0.0”.
Indicator Light
Mode Indicator Status
Power on without network Call button: Red light ashes once every 400ms.
Wi-Fi scanning mode
Card reader area: Flashes once every 400ms.
Call button: Always off
Pre-conguration mode
Card reader area: always on
Call button: Always off
Network conguration mode
Card reader area: always off
Call button: Blue light ashes once every 400ms.
Connect Wi-Fi
Success:
Card reader: Always off
Call button: Blue light is always on.
Failed:
Card reader: Always off
Call button: Purple light keeps ashing for 400ms.
