Voltage and Current Specications
AWG Sizes and Properties Table
Requirements
PoE or 12VDC 1A (EL-DB-WP only) power adapter suggested to power the device.
Power Supply 12VDC 1A
AWG 20 22 24
Resistance (ohm/km) 33.9 48.5 79.6
Cross-sectional Area (mm²) 0.5189 0.3247 0.2047
Wire Length (m) ≤50 ≤40 ≤20
1. Place the device away from sunlight and light sources to prevent potential damage.
2. Do not place the device in the high-temperature, and humid environments or in surroundings
impacted by magnetic eld.
3. Install the device on the at surface securely to avoid personal injuries and property loss caused
by device’s falling.
4. Do not use or place the device near heating objects.
5. If installing the device indoors, please keep device at least 2 meters away from light, and at least
3 meters away from window and door.
Backlight Direct sunlight Direct sun
through window
Indirect sunlight
through window
Close to light
