English – 9
EN
04
05
05
5
sec.
5
sec.
5
sec.
3
5
2
Note – When performing the procedure, at any time you can cancel it by keeping the n and t keys pressed simultaneously for 4 seconds. Otherwise, do not press
any key and wait 60 seconds for the motor to perform 6 movements.
––– Procedure 5.11 ––– executable only with a series transmitter Era P and Era W
04
05
05
5
sec.
5
sec.
5
sec.
1
sec.
PRG
1
sec.
PRG
1
sec.
PRG
3
4
2
2
3
5
5.12 - Memorisation of a climate sensor connected via radio (ref. paragraph 6.2.2)
To perform the procedure you must have a transmitter memorised in “Mode I”.
Before starting the procedure, move the shutter/awning to the mid-point of its stroke.
01. (on the climate sensor) Keep the yellow key pressed for 10 seconds and then release it (in this case the motor does not perform any movement).
02. (on the old transmitter) Give 3 pulses on the n key, provided that this is memorised.
03. (on the climate sensor) Keep the yellow key pressed for 2 seconds: the motor performs 3 movements to confirm its memorisation. Caution! – If the motor performs
6 movements, it means that its memory is full.
10
sec.
2
sec.
Old
“P1” “P1”
“P1”
X 3
0,5
sec.
3
N.B. – When performing the procedure, you can cancel the programming at any time by keeping the n and t keys pressed simultaneously for 4 seconds Alternatively,
do not press any keys and wait 60 seconds for the motor to perform 6 movements.
PROCEDURES FOR OPTIONAL ACCESSORIES (ref. Chapter 6)
