English – 23
English
MMM M
FLASHBUS STOP SbS
D
E
F
CA
39
B
Led P1 [D] Status Action
Off * All OK No memorisation in progress
On Memorisation in Mode 1 During memorisation in mode 1, it is normal for it to take a maximum of 10 s
Series of quick flashes, from
1 to 4
Memorisation in Mode 2 During memorisation in mode 2, it is normal for it to take a maximum of 10 s
5 quick flashes Cancellation OK Completion of deletion of a transmitter
1 slow flash Wrong command A command has been received from an unmemorised transmitter
3 slow flashes Memorisation OK Memorisation completed successfully
5 slow flashes Cancellation OK Completion of deletion of all transmitters
Led P2 [E] Status Action
Off * All OK “Slow” speed selected
On All OK “Fast” speed selected
1 flash per second The device recognition phase has
not been carried out, or there are
errors in the data saved
It is possible that there are faulty devices. Check and if necessary repeat
the device recognition phase (see paragraph 10.3.3 “Recognition of other
devices”)
2 flashes per second Devices recognition phase in pro-
gress
Indicates that it is in the process of recognising the attached devices (this will
take a maximum of a few seconds)
Led P3 [F] Status Action
Off * All OK Cycle operation
On All OK Complete cycle operation
1 flash per second There is no memorised opening
angle
Carry out the recognition phase (see chapter “3.5.2 - Leaf open and closure
angles recognition”).
2 flashes per second Opening angles auto-recognition
phase in progress
Indicates that the open angles self-learning phase is in progress
* or it could be in “Standby” mode
