20 – Robus 600-1000
PARAMETER
Bluebus
PHOTOCELLS
:
PHOTO II
PHOTO 1
PHOTO 1 II
PHOTO 2
PHOTO 2 II
PHOTO 3
FT A
FT B
FT C
OPEN PHOTO
OPEN PHOTO II
COMMANDS
:
CMD 1
CMD 2
CMD 3
CMD 4
DESCRIPTION
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the photocell is present, the relative operating sta-
tus and the correct memorisation in the control unit.
Indicates whether the sensitive edge is present, the relative operating
status and the correct memorisation in the control unit.
Indicates whether the sensitive edge is present, the relative operating
status and the correct memorisation in the control unit.
Indicates whether the sensitive edge is present, the relative operating
status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
Indicates whether the control photocell is present, the relative oper-
ating status and the correct memorisation in the control unit.
This function enables the display of the device type, operating status, and configuration of the devices connected to the Blue-
bus output. These parameters are described in Table 6.
TABLE 6: DIAGNOSTICS of bluebus devices
bluebus device diagnostics
Service voltage
Bus medium current
MOTOR 1
:
Torq u e
Speed
Voltage
Position
Indicates the voltage supplied to external devices.
Indicates the current absorption of the devices connected to the
bluebus output, calculated as a percentage.
Indicates the torque generated by motor 1 during the manoeuvre,
calculated as a percentage.
Indicates the speed of motor 1 during the manoeuvre, calculated as
a percentage.
Indicates the mean voltage to be supplied to motor 1 during the
manoeuvre, calculated as a percentage.
Indicates the physical position of the gate leaf, calculated as a per-
centage: the values concerned are the minimum limit of the leaf
when it reaches the closing limit switch (equal to 0%) and the maxi-
mum limit of the leaf when it reaches the opening limit switch (equal
to 100%).
