6 – English
EN
Mechanical limit switch setting
8 white Additional limit switch 2 CLOSE
7 green Additional limit switch 2 OPEN
6 white Additional limit switch 1 CLOSE
5 green Additional limit switch 1 OPEN
4 red Safety limit switch CLOSE
3 white Limit switch CLOSE
2 red Safety limit switch OPEN
1 green Limit switch OPEN
Optional
}
5c 5d
8
Manual release
Emergency maneuver
6
7
