Nice TOO Series User Manual

ENGLISH
1.1 - Safety warnings
• WARNING! - Important safety instructions. The following
instructions are critical for personal safety. Incorrect installa-
tion can result in serious injury.
Read these instructions with care before starting; in case of
doubt, contact Nice Support Service.
• WARNING! - Keep these instructions in a safe place to enable
future product maintenance and disposal operations.
• WARNING! – According to current European legislation, the
installation of an automatic door or gate must be in full obser-
vance of the standards envisaged by European Directive
98/37/EC (Machinery Directive) and in particular standards
EN 12445; EN 12453; EN 12635 and EN 13241-1, which enable
declaration of presumed conformity of the automation. Given
the above, all product installation, connection, programming
and maintenance work must be done exclusively by a skilled
and qualied technician, in observance of local laws, stand-
ards, regulations and the instructions in this manual.
1.2 - Installation warnings
• Before commencing the installation, check that this product is suit-
able for controlling your gate (see Chapters 3 and 9). If it is not suit-
able, DO NOT proceed with the installation.
• All product installation and maintenance must be done with the
automated mechanism disconnected from the power mains. Before
starting work, put a sign on the disconnection device that says
“CAUTION! MAINTENANCE IN PROGRESS” to the disconnection
equipment.
• Handle the product with care during installation, taking care to avoid
crushing, denting or dropping it, or contact with liquids of any kind.
Keeptheproductawayfromsourcesofheatandnakedames.Fail-
ure to observe the above can damage the product, and increase the
risk of danger or malfunction. Should this occur, suspend installation
work immediately and contact the Nice Support Service.
• Do not modify any part of the product. Operations other than as
speciedcanonlycausemalfunctions.Themanufacturerdeclinesall
liabilityfordamagecausedbymakeshiftmodicationstotheprod-
uct.
• If the gate or door being automated has a pedestrian gate, then the
system must include a control device that will inhibit the operation of
the motor when the pedestrian gate is open.
• Check that there are no points where people could become trapped
orcrushedagainstxedpartswhenthegateisfullyopen;ifthereare,
provide protection for these parts.
• The packing materials of the product must be disposed of in compli-
ance with local regulations.
1.3 - Warnings about use
• This product is not intended to be used by persons (including chil-
dren) whose physical, sensory or mental capacities are reduced, or
wholackthenecessaryexperienceorskill,unlesssuitableinstruc-
tions on how to use the product have been imparted by a person
responsible for their safety.
• Do not allow children to play with the automation.
•Donotallowchildrentoplaywithxedcontroldevices.Keepremote
control devices out of their reach as well.
• When operating the gate, keep an eye on the automated mechanism
and keep all bystanders at a safe distance until the movement has
been completed.
• Do not operate the automation if anyone is working nearby (cleaning,
etc.);disconnect its power supply before permitting such work to be
done.
• Check the automation frequently for imbalance, wear and damage.
Donotoperatethesystemifitneedsrepairoradjustment;haveit
servicedexclusivelybyqualiedandspecialisedtechnicians.
Contents
IMAGES ......................................... II - VII
Chapter 1 - WARNINGS AND GENERAL PRECAUTIONS
1.1 - Safety warning .................................... 1
1.2 - Installation warnings ................................ 1
1.3 - Operational warnings ............................... 1
Chapter 2 - PRODUCT DESCRIPTION AND INTENDED USE . 2
Chapter 3 - INSTALLATION
3.1 - Tests prior to installation ............................. 2
3.2 - Installation of the gearmotor .......................... 2
3.3 - Manually releasing the gearmotor ...................... 2
3.4 - Manually locking the gearmotor ....................... 2
Chapter 4 - ELECTRICAL CONNECTIONS ................ 2
Chapter 5 - TESTING THE AUTOMATION
5.1 - Testing .......................................... 2
5.2 - Commissioning ....................................3
Chapter 6 - OPTIONAL ACCESSORIES ................... 3
Chapter 7 - MAINTENANCE ............................ 3
Chapter 8 - DISPOSAL OF THE PRODUCT ................ 3
Chapter 9 - TECHNICAL SPECIFICATIONS. . . . . . . . . . . . . . . . 4
CE Declaration of Conformity .......................... 4
User manual (removable enclosure) ...................... II
1
WARNINGS AND GENERAL PRECAUTIONS
EN
1 – English

Nice TOO Series Specifications

General

Power supply (Vac/Hz)	230/50
Operating Voltage	230V
Max Gate Width	3 meters
Model	TOO Series
Control Type	External control unit (e.g., Nice control units)
Battery Backup	Optional, via compatible control unit and battery kit.
