CPU Bus
Com Status
Conditions affecting processor communication and their status
Monitoring
Tools
-Reset XPORT: Resets LAN port on SCHP board
-Default Password
-TFTP Status
CAN Bus
Viewer
Allows viewing CAN bus data for HC-MPU-2-TS board. Each string provides the ID
of the device and eight packets of Hex data bytes. This tool is intended to be used
in conjunction with MCE technical support
Version
Information
Software version information
Other Car
Settings
(display only;
reflects
duplex-
related
settings
)
- Emergency Power Type 2: As selected.
- Car 2 Floor (nn) Opening: Front/Rear/None per floor served by non-dispatch-
ing car of Duplex.
- Car 2 Floor Heights: Height in inches per floor served by non-dispatching car of
Duplex. Used by the Dispatching car to calculate ETA when making decisions
- Car 2 Contract Speed:
- Car 2 Top Floor:
- Car 2 Floor Eligibilities
- Opening
- CFSS
- Sabbath Up (Front/Rear)
- Sabbath Down (Front/Rear)
Address
Diagnostics
- Allows you to request selected processor register data via address entry. Techni-
cian assisted troubleshooting
Mainte-
nance
Statistics
Power cycles, Resets, Starts, etc.
Hourly
Statistics
Last 24 hours, per hour statistics for car calls, hall calls, up runs, down runs
Hall Bus
Inventory
With all hall calls installed and working, press INVTRY to inventory switches and
indicators. After Inventory is run, press TEST to test for switch or indicator prob-
lems
Table 5.2 Touchscreen Organization and Content
