PC Board Quick References
Manual # 42-02-1P28 A3 6-5
HC-CTL-2 Control Board
The HC-CTL-2 Control board monitors I/O, performs safety functions and provides front and
rear door operation. The HC-CTL-2 board is responsible for Inspection, Fire Service, Landing
System, door lock bypass, lanterns, and gongs.
Figure 6.3 HC-CTL-2 Control Board
Machine Room Inspection,
Test, and Door Bypass
Internal CAN
Connection
Fault Reset
Fault Bypass Jumper
