Diagram key : 1 Connection plug-in socket 12V 7 Lighting switch
2 Inside led bushing 8 Socket 12 V, 10 A, type 47 K
3 Wires bundle 9 Water pump switch
4 Plug-in connector 10 Waterpump
5 Fuse with holder 11 Integrated connector
6 Living space lighting 12 Terminal
Figure 6 : Diagram of the caravan living space lighting system 12 V for design N-126e.
10 vehicle mass b white
11 power supply k red
Diagram key : 1 Connection plug-in socket 12 V 7 Lighting switch
2 Inside led bushing 8 Socket 12 V, 10 A, type 47 K
3 Wires bundle 9 Water pump switch
4 Plug-in connector 10 Water pump
5 Fuse with holder 11 Integrated connector
6 Living space lighting 12 Terminal
3.5. Wiring system 220 V AC.
This system is designed for use the electricity power with voltage of 220 V AC and is suitable for
supply the equipment with the same voltage.
Diagram of the wire system 220 V AC is shown on fig. 7. Connection with power source is made with
25 meter cable (1) supplied with the caravan. Connect outdoor socket (2) of the caravan with
available electricity 220 V AC source, located near the caravan. The double socket (5) is assigned
as a power source for refrigerator and transformer 220V/12V. The single socket (4) gives a possibility
to use additional equipment with maximal power requirement of 1500 watt.
1 Connecting cable 25 meter 4 Single socket indoor
2 Socket outdoor 5 Double socket indoor
3 Current differential protection
