57
05-711
➊ ECG terminals ➏ load LED
➋ 230V~ power supply terminals ➐ 'select' button
➌ programming button ➑ control terminals
➍ programming LEDs ➒ 1-10V OUT terminals
➎ input LEDs
➋ ➊
➏
➎
➌ ➐
➍
fig. 1
➑ ➒
If everything has been connected correctly and the power is switched
on, all LEDs light simultaneously for 1s. You can now manually control
the connected lighting by means of the ‘select’ button. The ‘select’
button then functions as a 1-push button control.
EN
