EDG
Model
8x32 10x32 7x42 8x42 10x42
Product Number 7563 7564 7560 7561 7562
Focusing System CF CF CF CF CF
Magnification x 8 10 7 8 10
Objective Diameter
(mm) 32 32 42 42 42
Angular Field
Real
of View Apparent
7.8 6.5 8.0 7.7 6.5
57.2 59.2 52.2 56.6 59.2
FOV @ 1000 yds.
(ft.) 409 341 419 403 341
Close Focus Distance
(ft.) 8.2 8.2 9.8 9.8 9.8
Exit Pupil
(mm) 4.0 3.2 6.0 5.3 4.2
Relative Brightness 16.0 10.2 36.0 28.1 17.6
Eye Relief
(mm) 18.5 17.3 22.1 19.3 18.0
Size
(L&W) inches
mm
5.6
x5.3
5.6
x5.3
5.9
x5.4
5.8
x5.4
5.9
x5.4
142
x134
142
x134
149
x137
148
x137
151
x137
Weight
oz 23.6 23.6 28.6 28.6 28.9
grams 670 670 810 810 820
ACTION EXTREME ATB NIKON PROSTAFF COMPACT ATB TRAILBLAZER ATB
Model 7x35 7x50 8x40 10x50 12x50 16x50 8x25 9x25 10x25 12x25 8x25 10x25 8x42 10x50
Black 7237 7239 7238 7245 7246 7247 7483 7484 7485 7486 8217 8218 8220 8221
Camo N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 8219* 7530** 7531**
Focusing System CF CF CF CF CF CF CF CF CF CF CF CF CF CF
Magnification x 7 7 8 10 12 16 8 9 10 12 8 10 8 10
Objective Diameter
(mm) 35 50 40 50 50 50 25 25 25 25 25 25 42 50
Angular Field
Real
of View Apparent
9.3 6.4 8.2 6.5 5.5 3.5 6.3 5.6 5 4.2 8.2 6.5 7 5.6
59.3 42.7 59.7 59.2 59.8 52.1 47.5 47.5 47.2 47.5 59.7 59.2 52.1 52.1
FOV @ 1000 yds.
(ft.) 487 335 430 341 288 183 330 293 262 220 429 342 367 293
Close Focus Distance
(ft.) 16.4 23 16.4 23 23 23 9.2 9.2 9.2 9.2 8.2 11.5 16.4 16.4
Exit Pupil
(mm) 5 7.1 5 5 4.2 3.1 3.1 2.8 2.5 2.1 3.1 2.5 5.3 5
Relative Brightness 25 50.4 25 25 17.6 9.6 9.6 7.8 6.3 4.4 9.6 6.3 28.1 25
Eye Relief
(mm) 17.3 17.1 17.2 17.2 16.1 17.8 15.5 15.8 15.9 15.9 10 10 19.7 19.6
Size
(L&W) inches
mm
4.7
x7.2
7
x7.7
5.4
x7.4
7
x7.7
7
x7.7
7
x7.7
3.9
x4.5
4
x4.5
4
x4.5
4.1
x4.5
4.1
x4.5
4.1
x4.5
6.1
x5.2
7.4
x5.5
120
x184
179
x196
138
x187
178
x196
178
x196
177
x196
100
x116
101
x116
102
x116
103
x116
103
x114
103
x114
154
x131
187
x139
Weight
oz 28.2 35.3 30.1 36 36.8 36.7 12.5 12.7 12.9 12.9 9.9 9.9 23.6 29.1
grams 800 1000 855 1020 1045 1040 355 360 365 365 280 280 670 825
*Team REALTREE version finished in REALTREE APG HD
®
camo
**Advantage version finished in Advantage Max-1 HD
®
camo
MONARCH
®
ATB
Model 8.5x56 10x56 12x56 8x42 10x42 12x42 8x36 10x36
Black 7517 7518 7519 7430 7432 7437 7513 7514
Camo 7520** 7521** 7522** 7524* 7524* 7526* 7515** 7516**
Focusing System CF CF CF CF CF CF CF CF
Magnification x 8.5 10 12 8 10 12 8 10
Objective Diameter
(mm) 56 56 56 42 42 42 36 36
Angular Field
Real 6.2 6 5.5 6.3 6 5 7 6
of View
Apparent 49.4 55.3 59.9 47.5 55.3 55.3 52.1 55.3
FOV @ 1000 yds.
(ft.) 325 314 288 330 314 262 367 314
Close Focus Distance
(ft.) 32.8 32.8 32.8 8.2 8.2 8.2 8.2 8.2
Exit Pupil
(mm) 6.6 5.6 4.7 5.3 4.2 3.5 4.5 3.6
Relative Brightness 43.6 31.4 22.1 28.1 17.6 12.3 20.3 13.0
Eye Relief
(mm) 19.2 17.4 16.3 19.6 15.5 15.4 17.0 15.0
Size
(L&W) inches 7.8
x5.7
7.8
x5.7
7.8
x5.7
5.7
x5.0
5.6
x5.0
5.7
x5.0
4.9
x5.1
4.8
x5.1
mm
197
x144
197
x144
197
x144
146
x129
143
x129
146
x129
124
x129
122
x129
Weight
oz 40.2 40.7 41.6 21.5 21.5 21.8 20.1 20.3
grams 1140 1155 1180 610 610 620 570 575
*Team REALTREE versions finished in REALTREE APG HD
®
camo
**Dream Season versions finished in Mossy Oak
®
Obsession
™
camo
STABILEYES
®
Model 14x40 12x32 16x32
Product Number 8211 8212 8214
Focusing System CF CF CF
Magnification x 14 12 16
Objective Diameter
(mm) 40 32 32
Angular Field
Real
of View Apparent
4 5 3.8
52.1 55.3 55.9
FOV @ 1000 yds.
(ft.) 210 262 199
Close Focus Distance
(ft.) 16.4 11.5 11.5
Exit Pupil
(mm) 2.9 2.7 2
Relative Brightness 8.4 7.3 4
Eye Relief
(mm) 13 15 15
Size
(L&W) inches 7.3
x5.8
7
x5.6
7.1
x5.6
mm
186
x148
178
x142
181
x142
Weight
oz 47.3* 39.8* 39.5*
grams 1340* 1130* 1120*
*Weight without batteries
RANGEFINDERS Archer's Choice
w/ID Tech.
RifleHunter 550
w/ID Tech.
ProStaff Laser800 Laser1200
Measurement Range* (yds) 5-100 11-550 11-550 11-800 11-1200
Increment Reading** (yds) 0.5 0.5/1 0.5/1 0.5/1 0.5/1
Increment Reading in ID mode*** (yds) 0.2 0.2/1 N/A N/A N/A
Viewfinder Display m/YD m/YD m/YD m/YD m/YD
Magnification x 6 6 6 6 7
Angular Field
Real
of View Apparent
6 6 6 6 5
34.9 34.9 34.9 34.9 34
Eye Relief (mm) 18 18 18 18 18.6
Diopter Adjustment ±4 ±4 ±4 ±4 ±4
Power Source 1 CR2 lithium 1 CR2 lithium 1 CR2 lithium 1 CR2 lithium 1 CR2 lithium
Solid Color 8366ˇ(Green) 8367 (Brown) 8369 (Green) 8356 (Black) 8358 (Black)
Camo Finish N/Aˇ 8368ˇˇ 8370ˇˇˇ 8357 8359
Size (LxHxW)
inches
5.1
x2.7
x1.5
5.1
x2.7
x1.5
5.1
x2.7
x1.5
5
x2.8
x1.5
5.7
x3.2
x1.8
mm
130
x69
x37
130
x69
x37
130
x69
x37
126
x72
x37
145
x82
x47
Weight
oz 6.3 6.3 6.3 7.4 9.8
(w/o batteries)
grams 180 180 180 210 280
Objective Diameter (mm) 21 21 21 21 25
Exit Pupil (mm) 3.5 3.5 3.5 3.5 3.6
Safety & EMC for Archer’s Choice, RifleHunter 550 and ProStaff: class 1M laser product (IEC 60825-1:2001) class 1 laser
product (21 CFR 1040.10 and 1040.11) CE; EMC directive, Fcc Part 15 subpart B class B c-tick, VCCI class B, WEEE.
Safety & EMC for Laser800 & Laser1200: class 1 laser product (21 CFR 1040.10 and 1040.11) CE; EMC directive, Fcc
Part 15 subpart B class B c-tick, VCCI class B, WEEE.
*Results may vary based on weather conditions, target object’s shape or surface texture and other variables.
**First number is increment displayed out to 99.8 yards, second number is increment displayed past 100 yards
*** In Incline/Decline Mode, first number is increment displayed out to 99.8 yards, second number is increment
displayed past 100 yards. The origin of the technology behind this Laser Rangefinder with inclinometer is the
Total Station DTM-1 (initially sold in 1985), the first highly advanced electronic model among Surveying
instruments incorporating both distance and angle measurement capability developed by Nikon Corporation.
ˇArcher's Choice comes with REALTREE APG neoprene case
ˇˇRifleHunter camo model finished in Bill Jordan's Advantage MAX-1
ˇˇˇTeam REALTREE ProStaff model finished in REALTREE APG
— 49 —
Rangender/Binocular/StabilEyes Specications
The Kit contains four essential items to
create peak lens performance. Useful
for everything from sweeping dust and
other fine particles from lenses, remov-
ing residue, stains or marks from lenses,
and picking up small bits of dirt or
debris from hard-to-reach lens surface
positions.
Nikon Optics Maintenance Kit
Part # 7073
