104
ADVANCED PHOTOGRAPHY—DIOPTER ADJUSTMENT
Diopter Adjustment
The viewfinder is equipped with diopter adjustment to accommodate individual
differences is vision.
To adjust viewfinder diopter, pull the diopter knob out
and rotate it until the focus brackets in the viewfinder
are in sharp focus. Diopter can be adjusted in the range
between –3 m
–1
and +1 m
–1
. Corrective lenses (avail-
able separately) allow diopters of –3 m
–1
to +2 m
–1
.
Once you have adjusted diopter to your satisfaction, push
the diopter knob back into the body of the camera.
When operating the diopter knob, be careful to avoid injuring your eye with your finger or
fingernail.
For more information on:
pg. 198 Optional accessories
