TECHNICAL NOTES—SPECIFICATIONS
Self-timer Electronically controlled timer, duration 2–20 seconds
Combined electronic (CCD) and mechanical shutterShutter
Speed 30–
1
/
16,000
sec. (
1
/
3
increments), long time-exposure (bulb)
Flash
Sync contact
X-contact only; flash synchronization at speeds of up to
1
/
500
s
Flash sync modes Front curtain (normal) sync, red-eye reduction, red-eye reduc-
tion with slow sync, slow sync, rear curtain
Flash-ready light
Lights when SB-80DX, SB-50DX, SB-28DX, SB-28, SB-27, or SB-22s is
fully charged; blinks for three seconds after being fired at full output
Accessory shoe Standard ISO hot-shoe contact with safety lock
Sync terminal Standard JIS terminal with locking screw
Depth-of-field
preview button
Lens aperture stopped down when pressed
Remote control Remote control via 10-pin remote terminal or IEEE 1394 inter-
face (designed for speeds of up to 400 Mbps)
Monitor 2˝, 130,000-dot, low-temperature polysilicon TFT LCD with ad-
justable white LED backlight and brightness adjustment
Power source EN-4 Ni-MH Battery Pack, 7.2 V DC (can be recharged with op-
tional MH-17, MH-16 or MH-15 Quick Chargers); EH-4 AC adapter
(sold separately), 100 – 240 V AC
Tr ipod socket
1
/
4
˝ (JIS)
Dimensions
(W × H × D)
Approximately 157 × 153 × 85 mm (6.2˝ × 6.1˝ × 3.4˝)
Weight Approximately 1,100 g (2.5 lbs) excluding battery
Flash control • Automatic balanced fill-flash controlled by five-segment TTL
multi-sensor with single-component IC
-3D multi-sensor balanced fill-flash for D1 series (SB-80DX,
SB-50DX, or SB-28DX with type G or D Nikkor lens)
-
Multi-sensor balanced fill-flash (SB-80DX, SB-50DX, or SB-28DX
with AI-P Nikkor or Nikkor lens of a type other than type G or D)
•Auto-aperture (AA) flash (SB-80DX, SB-50DX, or SB-28DX with
CPU Nikkor lens)
•Non-TTL auto flash (with SB-80DX, SB-28DX, SB-28, SB-27,
SB-22s, and other Speedlights)
