Nikon D2X Repair Manual

VBA10501-R.3657.A
- Ｍ1 ･ -
Specications
Type
Single-lens reex digital camera with interchangeable lenses
Effective pixels 12.4 million
Image sensor 23.7 × 15.7 mm; total pixels: 12.84 million
Image size (pixels) 4288 × 2848 (L), 3216 × 2136 (M), 2144 × 1424 (S)
High-speed crop on I3216 × 2136 (L), 2400 × 1600 (M), 1600 × 1064 (S)
Lens mount Nikon F mount (with AF coupling and AF contacts)
Compatible lenses*
Type G or D AF Nikkor All functions supported
Micro Nikkor 85 mm
F2.8D
All functions supported except autofocus and some exposure modes
Other AF Nikkor † All functions supported except 3D color matrix metering and 3D
multi-sensor balanced ll-ash for digital SLR
AI-P Nikkor All functions supported except 3D color matrix metering, 3D
multi-sensor balanced ll-ash for digital SLR, and autofocus
Non-CPU Can be used in exposure modes A and M; electronic range nder can
be used if maximum aperture is f/5.6 or faster;color matrix metering,
multi-sensor balanced ll-ash for digital SLR, and aperture value
display supported if user provides lens data
* IX Nikkor lenses can not be used † Excluding lenses for F3AF
Picture angle Equivalent in 35-mm format is approximately 1.5 times lens focal
length (2 times when high-speed crop is on)
Viewnder Optical xed eye-level pentaprism
Diopter adjustment –3 – +1 m–1
Eyepoint 19.9 mm (–1.0 m–1)
Focusing screen Ships with type V clear-matte Mark III screen installed
Fame coverage Approximately 100% of lens (vertical and horizontal)
Magnication Approximately 0.86× (50-mm lens at innity; –1.0 m–1)
Re ex mirror Quick return
Lens aperture Instant return with depth-of-eld preview
Focus-area selection Single area or group can be selected from 11 focus areas (9
focus areas when high-speed crop is on)
Lens servo Instant single-servo AF (S); continuous-servo AF (C); manual (M);
predictive focus tracking automatically activated according
to subject status in single- and continuous-servo AF

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
