Nikon D2X Repair Manual

VBA10501-R.3657.A
- Ｍ2 ･ -
Autofocus TTL phase detection by Nikon Multi-CAM2000 autofocus module
Detection range
(ISO 100 at 20 °C / 68 °F)
–1 – +19 EV (0 – +19 EV for two focus areas outside high-speed
crop)
AF-area mode Single-area AF, dynamic-area AF, group dynamic-AF, dynamic-area
AF with closest subject priority
Focus lock Focus can be locked by pressing shutter-release button halfway
(single-servo AF) or by pressing AE-L/AF-L button
Exposure
Metering Three-mode through-the-lens (TTL) exposure metering
Matrix 3D color matrix metering supported with type G and D lenses;
color matrix metering available with other CPU lenses and with
non-CPU lenses if user provides lens data
Center-weighted Weight of 75% given to 6, 8, 10, or 13-mm circle in center of
frame, or weighting based on average of entire frame
Spot Meters 3-mm circle (about 2% of frame) centered on selected
focus area (on center focus area when non-CPU lens is used)
Range
(ISO 100 equivalent,
f/1.4 lens, 20 °C/68 °F)
0 – 20 EV (3D color matrix or center-weighted metering)
2 – 20 EV (spot metering)
Exposure meter coupling Combined CPU and AI
Exposure control
Exposure modes Programmed auto with exible program; shutter-priority auto;
aperture priority auto; manual
Exposure compensation
–5 – +5 EV in increments of 1/3, , or 1 EV
Bracketing Exposure and / or ash bracketing (2–9 exposures in increments
of 1/3, , 2/3, or 1 EV)
Exposure lock Luminosity locked at detected value with AE-L/AF-L button
Shutter Electronically-controlled vertical-travel focal-plane shutter
Speed
30 – 1/8000 s in steps of 1/3, , or 1 EV, bulb
Sensitivity
(ISO equivalent)
100 – 800 in steps of 1/3, , or 1 EV, 1600, 3200; auto gain to 800
White balance Auto (TTL white-balance with main image sensor, 1,005 pixels
RGB sensor, and ambient light sensor), six manual modes with
ne-tuning, color temperature setting
Bracketing 2–9 exposures in increments of 1, 2, or 3

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
