Chapter
1 Before
Use
2 Componen
ts
- 2 -
2
Components
Check that all items listed b
elow are provided in the pac
kage.
If any items are missing
, contact your nea
rest
Nikon representa
tive immediately.
1
DS-U3 DS Camera Control Unit
6 Power
cord
2 Vertical
stand
7
DS camera cable (DS Ca
mera I/F cabl
e
20-26; 3 m)
3 Instruction
manual
8
DS Camera Head with a C mo
unt cap
4
NIS-Elements freeware packa
ge (CD-ROM)
9
C mount adapter (optional)
5 AC
adapter
9
11
