Chapter 4 Connecting and Installing the Equipment
1 Connection Diagrams
- 10 -
Trigger signal output device
(Can be connected only when
DS-Qi1Mc is used.)
DS AC adapter DS camera head
DS
camera
cable
PC
CAMERA 2 connector CAMERA 1 connector
(2) Connectors (Rear of the DS-U3)
DC IN 12V IEEE1394 CAMERA1 CAMERA2 EXT.I/O
