Side
25
of
27
System dimension
VPL 15 Top
VPL 15
1:
Udelu
ft
,
Fresh Air
,
Aussenluft
,
Air neu
f
2: Tilluft
,
Air Inlet
,
Zu
luft
,
Air
pulse
3: Fraluft
,
Air Exhaust
,
A
bluft
,
Air repris
4: Afkastlu
ft
,
Air Disc
harge
,
Fortluft
,
Air extrait
11: Kondensa
fløb, Evacuation conde
rsats, Kondensatmu
ffe, Vacuation des condensa
ts
24
26
