This document may be subject to change Side 9 of 27
IMPORTANT regarding Danfoss Actuator type AME 140:
Re-installing the actuator must be done as described below:
1. Disconnect the power supply and remove the cover of the actuator.
2. Liberate the gear by pressing down the button as the spindle is turned up (counter clock-
wise)
3. Re-install the actuator and turn on power.
4. DIP-switch nr. 1 should be moved to ON and then to OFF.
5. The actuator is automatically calibrating for up to 6 minutes.
(The LED is flashing when calibrating and is lit constantly when finished).
6. Re-install the cover of the actuator.
Permissible ambient temperature for Danfoss Actuator type AME 140/24 V is 0 ° C to 55 ° C.
Actuators are IP42 and therefore not suitable for mounting in the open..
See electrical chart.
