Nile 4500PP - Desktop Set Up; Wall Mounting

AUTO TOTALING TIME CLOCK INSTRUCTIONS
Model 4500PP
4 WALL MOUNTING 888.479.7264
DESKTOP SET UP
WALL MOUNTING
Remove time clock from carton and place on a at, level surface.
Plug unit into AC wall outlet.
Select a location convenient to employees
clocking IN and OUT. Be sure power outlet is
within 4 feet of mounting location.
Use masking tape to hold mounting template
(located on last page) on wall, making certain
template is positioned so bottom of time clock
is approximately 45 inches from oor.
Drill holes using template as a guide.
Remove template from wall and install #10
screws, leaving approximately 3/16 inch of screws
exposed. For sheetrock walls, use plastic anchors.
Hang time clock on wall, aligning keyholes on the
rear with screw heads. Press downward on time
clock until it lowers onto screws.
Plug unit into AC wall outlet.
It is recommended to remove the clock from
bracket to complete programming set up which
begins on page 5.
2
2
3
4
5
6
1
1
Model 4500PP
7
