NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 305-238-4373
3
Bracket
New Construction Wings
Frame
Loudspeaker Baffl e
Acoustic Fine
Tuning Controls
Grille
Figure 1. Mounting an HDFX vertically into a wall
INSTALLATION CONSIDERATIONS
