2
PRODUCT OVERVIEW
Display – Backlit LCD displays system
information from iPod, XM, SIRIUS, AM/FM
and functions associated with “Soft Keys”
Soft Keys
3 backlit
buttons that
change function
depending
upon the source
selected
Cursor Keys
5 backlit
buttons provide
navigation of
menus, playlists
and favorites
Master Keys
8 backlit buttons provide
“One Touch to Music”
OFF
Backlit button turns zone or
entire system off
PREV/NEXT
2 backlit buttons default
to Next or Previous /
Track or Station
Alphanumeric
Keys – Provide
direct access
tuning, numeric
selection of track
and alphabetic
search for iPod
DISPLAY
Turns on
backlight and
LCD display
screen and
buttons
MUTE
Backlit button
mutes/un-mutes
audio output to
zone
VOL–/VOL+
2 backlit buttons adjust
volume up or down
Niles System Settings
Provides access to system
settings: audio (bass, treble,
balance), sleep timer, alarm
clock, etc.
Figure 1: IntelliControl ICS Display Keypad–front view.
