W ALL M OUNTED P ROGRAMMABLE IR K EYPAD S YSTEM
Specifications
IR System
Compatible with virtually all brands of remote
controls using carrier frequencies between 23
and 107kHz
Wiring Requirements
IR Data and Status
Up to 500’ Individual home-runs of 2-conductor
shielded cable, West Penn D291 or equivalent
Speaker Relay
Individual runs of 2-conductor speaker wire,
14-22 gauge
Stand Alone Status Feedback
Up to 200’ of 2-conductor wire, 14-16 gauge
Local Flasher Output
Up to 200’ of 2-conductor wire, 14-16 gauge
Speaker Relay Power Handling
200 Watts/channel continuous RMS power
FCC Certification
Class “B” certified for use in a residential envi-
ronment
Mounting
In-wall, fits into most36 cubic. inch double-
gang electrical boxes at least 2 3/4” deep,
Decora-style faceplate
Unit Dimensions
3 1/2” wide x 2 9/16” high x 2” deep
Face Plate Dimensions
Decora wall plate; 4 9/16” wide x 4 1/2” high
Depth Behind Plate
2 1/2”
DS00154A/IntelliPad 2/5/99 4:32 PM Page 1

Niles IntelliPad Specifications

General

Brand	Niles
Model	IntelliPad
Category	Keypad
Language	English
