19
I
NFRARED MAIN SYSTEM UNIT
Specifications
IR System
Compatible with virtually all brands of
remotes using carrier frequencies
between 26 and 105kHz.
W
iring Requirements
Individual home-runs of category 5 cable
from each sensor/keypad.
Unit Dimensions
5-11/16” wide x 1-1/4” high x 2” deep.
Power Requir
ements
12VDC power supply (included).
Contents
MSU250 1
Screwless Connectors 2
In-line Power Supply 1
Self-Adhesive
Rubber Feet 4
DS00328ACN_MSU250.qxp 2/27/04 10:10 AM Page 19
