SPECIFICATIONS
Recommended Amplifier Power
Five to one hundred watts per channel
Nominal Impedance
8 Ohms
Frequency Response
65 Hz to 21kHz, plus or minus 3 dB (on axis)
Sensitivity
89 decibels for 1.83 volts of Pink Noise, measured at 1 meter on axis
Wiring Requirements
Sixteen to eighteen gauge 2-conductor (unshielded or shielded) wire for runs
up to eighty feet. Fourteen gauge 2-conductor (unshielded or shielded) wire for
runs up to two hundred feet.
Temperature Extremes
-50° to 200° Fahrenheit
Dimensions (Speaker without U-Bracket)
8-3/8" Wide x 11" High x 6-11/16" Deep
Dimensions (Speaker with U-Bracket)
8-3/8" Wide x 11" High x 7-9/16" Deep
Weight (Speaker and Bracket)
6-1/2 lbs.
SPECIFICATIONS
19
