Niles ZR-4 Installation Guide

NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 305-238-43732
Thank you for purchasing the Niles ZR-4 MultiZone Receiver Kit. With proper installation and operation, you should enjoy years of
trouble-free use.
Niles manufactures the industry’s most complete line of custom installation components and accessories for audio video systems. To see
the complete Niles product assortment, visit us on the Internet at: www.nilesaudio.com.
Introduction 1
Features and Benefits 2
Contents 3
Parts Guide 3
Installation Considerations 5
System Configurations (Applications) 6
System Installation 14
Keypad Installation 17
Configuring the MultiZone Receiver 18
Configuring the Zone 21
Configuring the Hand-Held Remote 22
Operating the ZR-4 MultiZone Receiver 24
Troubleshooting 25
Hand-Held Remote Control Troubleshooting 26
Specifications 27
Notes 28
CONGRATULATIONS!
TABLE OF CONTENTS

Niles ZR-4 Specifications

Weight and Dimensions

width	4 3/4" (12 cm)
height	1 1/4" (3.2 cm)
depth	2" (5.1 cm)
shipping weight	1 lb. (.5 kg)
