Niles ZR-4 Specification Sheet

SSSS
S
P
P
P
P
P
EE
E
E
E
CCCC
C
C
I
I
I
I
F
F
F
F
F
I
I
I
I
I
CCCC
C
C
C
A
A
A
A
A
A
TT
T
T
T
T
I
I
I
I
OOOO
O
O
O
NNNN
N
N
N
SS
S
S
S
S
S
SS
S
H
H
H
H
H
H
E
E
E
E
E
E
E
E
E
T
TT
T
Specifications
ZR-4
4 Source, 4 Zone Audio MultiZone
Receiver Kit with AM/FM Tuner
Includes: MultiZone Receiver, Rack Mount
Ears, Four IR Weather-Resistant Keypads,
Hand-Held Learning Remote Control, Three
Infrared MicroFlashers
®
Packaged as a complete system
Model Stock Number
Standard FG01431
Export FG01529
UK FG01432
*
Features
■ Distributes up to four sources to four zones to create a basic audio system
■ Built-in AM/FM tuner stores 20 preset stations, provides out-of-the-box radio
operation and eliminates the need for an additional component, connections,
and programming
■ Built-in eight-channel digital amplifier delivers 40 watts per zone (20 watts per
channel) to each of the four zones
■ RS232 and discrete IR control for each of the four zones provides seamless
integration with third-party remote control systems
■ Preamplifier outputs and a 12V trigger make it easy to add additional power
with Niles Systems Integration Amplifiers
®
■ Paging input accommodates voice announcements from a telephone and/or
doorbell tones from the optional Niles DBI-1 interface
■ Independent bass, treble and variable loudness tone controls enable the
customization of each zone to optimize performance
■ Rugged, 1U aluminum front panel and included mounting ears make rack
mounting secure while taking up minimal space
■ System architecture allows expansion to eight zones via an additional ZR-4
MultiZone Receiver
■ The ZR-4 supports an additional keypad in each zone, ideal for large rooms
(additional keypads sold separately; requires ZR-KE Keypad Splitter)
■ Zone linking lets the ZR-4 permanently group up to four zones per chassis:
turn-on, source selection, and turn-off all work in unison, yet each zone has
independent volume, bass, treble and variable loudness control
■ Phantom home theater zone enables source sharing with independent home
theater system via global IR input and home theater sync
■ Three external audio source inputs
■ Gold-plated RCA audio jacks
■ Removable speaker connectors accommodate up to 16-gauge wire
■ 75 ohm FM antenna connection, 300 ohm AM antenna connection (AM and
FM antennas included)
■ RJ-45 keypad connections use T-568A CAT-5 termination
■ Removable two-wire IEC line cord
Solo
®
-4 IR Weather Resistant Keypad
■ Provides control for the ZR-4’s built-in tuner and up to three additional sources.
Controls source selection and local zone volume, muting and turn off. Can also
turn the entire system on or off with a single press of a button
■ Weather-resistant design enables installation in spas, showers or outdoor areas
■ Features an integrated plasma/LCD-proof IR sensor
■ Includes assorted laser-etched buttons for custom labeling of keypad
■ Dimensions: Standard version fits 1-gang electrical box
■ UK version includes 85 mm keypads that are illustrated with blue lighting and fit
into standard 70 mm square boxes.
R-6L Hand-Held Learning Remote Control
■ Provides advanced control for the system’s audio sources as well as the local TV
and associated cable/satellite receiver. It comes preloaded with the commands
for the ZR-4 as well as many popular brands of equipment. The R-6L can quickly
learn almost any unique codes and has the ability to create IR sequences.
Specifications
■ Safety certifications: CSA-E65 listed, tested
under UL6500 standards
■ Dimensions: 17 1/4” wide x 1 3/4” high x
13” deep including connection terminals with
no wires attached (43.8cm wide x 4.5cm high
x 33cm deep)
■ 1U rack height
Warranty: Two-year limited
Shipping weight: 15 lbs. (7 Kg)
ZR-4 Standard/Export
ZR-4 UK Series 2
*
*
Includes 85 mm keypads that are illuminated with
blue lighting and fi t into standard 70 mm boxes.

Niles ZR-4 Specifications

Weight and Dimensions

width	4 3/4" (12 cm)
height	1 1/4" (3.2 cm)
depth	2" (5.1 cm)
shipping weight	1 lb. (.5 kg)
