Nilfisk-ALTO POSEIDON 2-26 PORTABLE User Manual

42
POSEIDON 2-24 PORTABLE POSEIDON 2-26 PORTABLE
Voltage 230 V / 1~/ 50Hz DK EU DK EU
Fuse A 10 10
14 14
Power rating kW
2.2 2.2 3.2 3.2
Working pressure bar (MPa)
100 (10) 100 (10)
140 (14) 140 (14)
Volume flow (max.) l/h
650 650
610 610
Volume flow Q
IEC
l/h
600 600
540 540
Max. water inlet temperature °C 50
Max. water inlet pressure bar (MPa)
10 (1)
Dimensions lxwxh mm 555 x 290 x 275
Weight kg 24 24 26 26
Noise level at a distance of 1 m EN 60704-1 dB(A)
86.8 86.8 86.8 86.8
Sound pressure dB(A)
99.2 99.2 99.2 99.2
Torque N
17 17 20 20
Oil quantity in pump ml 150
Oil type HV68
EN
8.2 Guarantee
Our general conditions of busi-
ness are applicable with regard
to the guarantee. Subject to
change as a result of technical
advances.
8.3 Technical Specifications
8.4 EU Declaration of
Conformity
8.5 Accessories
EU Declaration of Conformity
Product:
High Pressure Washer
Type:
Poseidon 2-24 Portable, Poseidon 2-26 Portable
Description:
400 V 3~, 50 Hz - 230 V 1~, 50 Hz - IP X5
The design of the unit corresponds to
the following pertinent regulations:
EC Machine Directive 98/37/EEG
EC Low-voltage Directive 73/23/EEG
EC EMV Directive 89/336/EEG
Applied harmonised standards:
EN 292-1, EN 292-2, EN 60335-2-79
EN 55014-1, EN 55014-2, EN 61000-3-2
Applied national standards and technical
specifi cations:
DS EN 60335-2-79
Anton Sørensen
V.P. Technical Operations Europe
Nilfi sk-ALTO
Division of Nilfi sk-Advance A/S
Industrivej 1
DK-9560 Hadsund
Hadsund, 01.06.2004
Poseidon
Portable
High pressure hose 3/8" Turbo-hammer Cross grip Powerspeed Vario
15 m 20 m 50 m
2-24
1402064 1402072 1402759 106402178 106402110 106402182
2-26
1402064 1402072 1402759 106402177 106402110 -
